Name: ZBS-TWINLIGHT Emergency Lighting Luminaire
Brand: ZBS Elektronik
SKU: ZBS-70180
Availability: InStock

Emergency Lighting Luminaires Model: ZBS-70180

ZBS-TWINLIGHT emergency lighting luminaire; 2x650–2x1000 lm, 60/180 minutes autonomy, maintenance-free battery, optional plug-in cable.

Battery: 6 V – 12 V maintenance-free batter...
Mounting: Surface mounted / Portable
IP Rating: IP40
Light Source: LED — illuminates in emergency mod...

Request a Quote Product Catalogue (PDF)

CE certified, manufactured to the EN 60598 series of standards
Produced under the ISO 9001:2015 quality management system
2-year product warranty; extended life with the LiFePO4 battery option
Technical support and after-sales maintenance directly from the manufacturer

Product description

ZBS-TWINLIGHT is an emergency lighting luminaire with an ABS housing and polycarbonate heads that can also be used plugged into a socket thanks to its optional 220 V cable.

Model codes ZBS-70180, ZBS-07560 and ZBS-075180 deliver between 2x650 lm and 2x1000 lm, with 60 and 180 minute autonomy options. An ON-OFF switch, green charge LED and manual test button are standard.

Technical specifications

Test: Manual test button
Cable: 220 V cable with plug
Battery: 6 V – 12 V maintenance-free battery
Housing: ABS plastic
Mounting: Surface mounted / Portable
IP Rating: IP40
Standards: EN60598-1, EN60598-2-22, EN60598-2-11, IEC61547:2020
Lamp heads: ABS + polycarbonate (PC)
Light Source: LED — illuminates in emergency mode
Charging Time: 24 hours
Charge Indicator: Green charge LED, ON-OFF Butonlu
Electrical Class: I
Operating Voltage: 230V AC 50/60Hz
Emergency Autonomy: 180 Dakika
Operating Temperature: -5 C° / +45 C°
Mains Power Consumption: 3,5W

Model list

ZBS-TWINLIGHT Emergency Lighting Luminaire model codes and dimensions

ZBS-TWINLIGHT Emergency Lighting Luminaire — model code, operating mode, autonomy and housing dimensions.
Model Code	Operating Mode	Autonomy	Lamp Output	Lumen	IP Rating	Dimensions	Operating Temperature	Power Consumption	Operating Voltage
ZBS-70180	Non-maintained	180 min	2x14F LED 2x9 Watt	2x650 LM	40	100X300X295 mm	-10 / +60 °C	3,5 W	220-240 V
ZBS-07560	Non-maintained	60 min	2x30 F LED 2x15 Watt	2x1000 LM	40	100X300X295 mm	-10 / +60 °C	3,5 W	220-240 V
ZBS-075180	Non-maintained	180 min	2x30 F LED 2x15 Watt	2x1000 LM	40	100X300X295 mm	-10 / +60 °C	3,5 W	220-240 V
